FEATURES

• Constructed with construction-grade 5/8" copolymer 3-strand twisted rope
• Steel thimble and splice-protecting shrink tube are included for lasting durability
• Includes alloy steel snap hook for anchorage connection
• Back-spliced trailing end is ideally suited for pairing with hinged arresters and adjusters
• Complies with ANSI Z359.15-2014

MATERIAL SPECIFICATIONS

Rope3-strand twisted copolymer; 5,000 lbs. Min.

ConnectorPlated alloy steel; 5,000 lbs. Min. static strength with 3,600 lbs. gate strength

ThimblePlated Carbon Steel

PERFORMANCE SPECIFICATIONS

Static Strength5,000 lbs. Min.

ANSI User Capacity130 to 310 lbs. Max.

OSHA User Capacity130 to 310 lbs. Max.
