Apollo™ 76F10301A 76F-100-A 2-Piece Standard Configuration Ball Valve, 1/2 in Nominal, FNPT End Style, Stainless Steel Body, Full Port, MPTFE Softgoods, Domestic
23121131
MFG #: 76F10301A
$0.00
/ Each
In Stock
- Actuator Type: Lever Operated
- Ball Material: 316 Stainless Steel
- Body Material: Stainless Steel
- Domestic/Import: Domestic
- End Style: FNPT
- Inlet to Outlet Length: 2.35
- Media: Water
- Nominal Size: 1/2
- Port Type: Full
- Pressure Rating: 1000 psi CWP
- Series: 76F-100-A
- Softgoods Material: MPTFE
- Top to Inlet Center: 1.73
- Trim Material: 316 Stainless Steel/PTFE
- Type: 2-Piece
Apollo™, 76F10301A, Standard Configuration Ball Valve, 2-Piece, Series: 76F-100-A, 1/2 in Nominal, FNPT End Style, 1000 psi CWP Pressure, Full Port, Media: Water, Lever Operated Actuator, 316 Stainless Steel Ball, 2.35 in Inlet to Outlet Length, 1.73 in Top to Inlet Center, Stainless Steel Body, 316 Stainless Steel/PTFE Trim, MPTFE Softgoods, Domestic
- Investment cast comp
- Blow-out proof stem
- Vacuum service to 29
- 304 stainless steel
- RPTFE (1/2 to 3 in)
- Stainless steel with
- 150 psig saturated s
Investment cast components
Blow-out proof stem design
Vacuum service to 29 in Hg
304 stainless steel lever nut
RPTFE (1/2 to 3 in) body seal
Stainless steel with vinyl lever and grip
150 psig saturated steam/body seal
