Anvil® 0500361159 FIG 261 Riser Clamp, 12 in Pipe, 5/8 in Dia Bolt, 2700 lb Load, Carbon Steel, Galvanized, Domestic
Part #09900660
Legacy #09900660
MFG #0500361159
Anvil® Riser Clamp, Series: FIG 261, 12 in Pipe, 5/8 in Bolt Dia, 2700 lb, 450 deg F, 100 ft-lb, Carbon Steel, Galvanized, 22-3/4 in L x 2 in W, Domestic
/ Each
Product Attributes
Brand : Anvil®
Series : FIG 261
Pipe Size : 12
Bolt Diameter : 5/8
Load Capacity : 2700
Temperature Rating : 450
Product Documents
Product Features
- For support of stationary steel pipe risers, cast iron pipe or conduit.
- Clamp is fitted and bolted preferably below a coupling, hub or welded lugs on steel pipe
- Clamp is fitted and bolted preferably below a coupling, hub or welded lugs on steel pipe
- Bolt torques should be PEX industry standards
- Bolt torques should be PEX industry standards
- Clamp is designed for standard steel pipe O.D and this must be considered in sizing the riser for other types of piping
- Clamp is designed for standard steel pipe O.D and this must be considered in sizing the riser for other types of piping
