Features

• Anti-panic function provides the safest solution available for vertical rope attachment
• Hinged design allows user installation at any point on the lifeline.
• Trailing mobility follows ascending and descending user with minimal effort
• Energy absorber features patented ViewPack® cover with inspection window
• For use with 5/8" diameter synthetic rope lifelines
• Includes alloy steel fall arrester for lifeline connection and snap hook for harness attachment
• Complies with ANSI Z359.15-2014



Material Specifications

Webbing:  Polyester; 5,000 lb min. static strength
Energy Absorber:  Polyester tear-away
Fall Arrester:  5/8" Fall Arrester/Grab; Plated alloy steel; 5.000 lb min.
Connector:  Plated alloy steel; 5,000 lb min. static strength with 3,600 lb gate strength



Performance Secifications

Static Strength:  1,800 lb min.
ANSI Lanyard Class:  6' free fall
Max. Arrest Distance:  11'
Avg. Arrest Force:  900 lb
Max. Arrest Force:  1,800 lb
ANSI User Capacity:  130 to 310 lb max.
OSHA User Capacity:  130 to 310 lb max.
